G. Prepare for the Installation
SUBTASK 47-32-01-430-001
(1) Do these steps to prepare the NGS shutoff valve [1] for the installation:
(a) Make sure that the lockpin [8] is stowed in the servo housing, and fully tightened.
(b) Make sure that the visual position indicator points to the CLOSED position.
SUBTASK 47-32-01-010-001
(2) Go to the NGS shutoff valve [1] location in the left air conditioning bay.
SUBTASK 47-32-01-090-001
(3) Remove the protective covers from the ozone converter [6] and the bleed air inlet duct [2].
SUBTASK 47-32-01-100-001
(4) Make sure that the NGS shutoff valve [1], ozone converter [6], seal [3], coupling [4], and
coupling [5] are clean, free from grease and unwanted materials.
SUBTASK 47-32-01-110-001
(5) To clean the components, do this task: General Cleaning of Metal (Series 80),
TASK 20-30-80-910-801.
SUBTASK 47-32-01-110-002
(6) Prepare these components for an electrical faying surface bond (SWPM 20-20-00):
(a) mating surfaces of the NGS shutoff valve [1]
(b) mating surfaces of the coupling [4]
(c) mating surfaces of the coupling [5]
(d) mating surfaces of the ozone converter [6]
(e) mating surfaces of the bleed air inlet duct [2].
SUBTASK 47-32-01-390-001
WARNING
KRYTOX 240AC IS AN AGENT THAT IS POISONOUS AND AN IRRITANT.
MAKE SURE ALL PERSONS OBEY THE PRECAUTIONS WHEN KRYTOX
240AC IS USED.
• DO NOT USE IN AREAS WHERE THERE IS HIGH HEAT, SPARKS, OR
FLAMES.
• CLOSE THE CONTAINER WHEN NOT USED.
• DO NOT GET KRYTOX 240AC IN THE EYES, ON THE SKIN, OR ON YOUR
CLOTHES.
• DO NOT BREATHE THE GAS.
• DO NOT EAT KRYTOX 240AC.
(7) Apply a thin layer of Krytox 240AC perfluoropolyether grease, D50063, or water, on the
seal [3].
SUBTASK 47-32-01-430-002
(8) Install the seal [3] in the cavity of the NGS shutoff valve [1] and the ozone converter [6].
H. Install the NGS Shutoff Valve
SUBTASK 47-32-01-420-001
(1) Do these steps to install the NGS shutoff valve [1]:
(a) Align the NGS shutoff valve [1] with the bleed air inlet duct [2].
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-32-01
Page 407
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590,
592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999;
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518,
524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703,
707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
