2) Remove the fasteners for this access panel [21]:
Number Name/Location
195BL Wing To Body Fairing - Left Side
3) Remove the fasteners for this access panel [22]:
Number Name/Location
195CL Wing To Body Fairing - Left Side
(d) Zone 196:
1) Remove the fasteners for this access panel [23]:
Number Name/Location
195AR Wing To Body Fairing - Right Side
2) Remove the fasteners for this access panel [24]:
Number Name/Location
195BR Wing To Body Fairing - Right Side
3) Remove the fasteners for this access panel [25]:
Number Name/Location
195CR Wing To Body Fairings - Right Side
(e) Remove the fairing panel from the airplane.
END OF TASK
TASK 53-51-21-400-802
5. Center Wing-To-Body Fairing Panel Installation
(Figure 402)
A. General
(1) This task includes the steps to install access panels:
B. References
Reference Title
34-32-11 P/B 401 MARKER BEACON ANTENNA - REMOVAL/INSTALLATION
34-55-11 P/B 401 DME ANTENNA - REMOVAL/INSTALLATION
51-00-59 STANDARD PREVENTIVE MAINTENANCE PROCEDURES
51-51-00-340-805 Bonded Teflon Rub Pad Repair (P/B 801)
52-48-42-400-801 Environmental Control Systems (ECS) Access Door -
Installation (P/B 401)
53-51-21-211-801 Wing-To-Body Fairing Panel Designated Electrical Bond Visual
Inspection (P/B 601)
53-51-21-760-801 Wing-To-Body Fairing Panel Maximum Electrical Resistance
Check (P/B 601)
C. Consumable Materials
Reference Description Specification
A00247 Sealant - Pressure And Environmental -
Chromate Type
BMS5-95
A02315 Sealant - Low Density, Synthetic Rubber. 2
Part
BMS5-142 Type II
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-51-21
Page 412
D633A101-ILF Oct 15/2015
