(Continued)
Reference Description Specification
C00175 Primer - Urethane Compatible, Corrosion
Resistant
BMS10-79 Type III
C00259 Coating - Chemical And Solvent Resistant
Finish, Corrosion Inhibiting Primer
BMS10-11 Type I
C00308 Compound - Corrosion Preventive, Petrolatum
Hot Application
MIL-C-11796
C00528 Compound - Corrosion Preventive, Petroleum
Hot Application (Soft Film)
MIL-C-11796 Class III
G00009 Compound - Organic Corrosion Inhibiting BMS3-23
D. Location Zones
Zone Area
192 Lower Wing-To-Body Fairing - Under Wing Box
193 Lower Wing-To-Body Fairing - Wheel Well
195 Above Wing, Wing-To-Body Fairing - Left
196 Above Wing, Wing-To-Body Fairing - Right
E. Access Panels
Number Name/Location
192AL Underwing Bolt Cover - Forward
192AR Underwing Bolt Cover - Forward
192BL ECS Ram Air Inlet Mixing Duct Panel - Forward
192BR ECS Ram Air Inlet Mixing Duct Panel - Forward
192E ECS Under Keel Panel - Forward
192F ECS Under Keel Panel - Middle
192G Sump Drain Access Door
192HL Underwing Bolt Cover - Aft
192HR Underwing Bolt Cover - Aft
192JL Air Conditioning Panel - Aft
192JR Air Conditioning Panel - Aft
192K Air Conditioning Under Keel Panel - Aft
193AL Wheel Well Panel - Forward Outboard
193AR Wheel Well Panel - Forward Outboard
193B Wheel Well Panel - Forward Inboard
193CL Wheel Well Panel - Aft Outboard
193CR Wheel Well Panel - Aft Outboard
193D Wheel Well Panel - Aft Inboard
195AL Wing To Body Fairing - Left Side
195AR Wing To Body Fairing - Right Side
195BL Wing To Body Fairing - Left Side
195BR Wing To Body Fairing - Right Side
195CL Wing To Body Fairing - Left Side
195CR Wing To Body Fairings - Right Side
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-51-21
Page 413
D633A101-ILF Oct 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
To Next Page
