(Continued)
AMM Item Description AIPC Reference AIPC Effectivity
1 (cont.) 30-41-11-03-005 ILF 101, 151, 156-199,
331-399, 491-500, 535,
537, 553-557, 559-564,
567-569, 573-577, 581,
583, 585, 588-590,
592-599, 601-603, 606,
607, 610-615, 620,
625-627, 671, 672, 686,
691-699, 709, 710,
804-807, 812, 821, 822,
831-838, 841, 842, 851,
852, 854-858, 861-863,
871-874, 947, 948,
968-973, 980-999
30-41-11-04-005 ILF 301, 304, 308, 310,
314, 315, 317-319, 323,
402, 424, 425, 427-429,
451, 452, 501-504,
507-510, 512-516,
518-520, 523-528,
530-533, 536, 541, 542,
552, 571, 572, 703, 707,
708
D. Location Zones
Zone Area
117 Electrical and Electronics Compartment - Left
118 Electrical and Electronics Compartment - Right
E. Access Panels
Number Name/Location
117A Electronic Equipment Access Door
F. WHCU Installation
SUBTASK 30-41-11-860-012
(1) Make sure that these circuit breakers are open and have safety tags:
CAPT Electrical System Panel, P18-3
Row Col Number Name
D 1 C00226 WINDOW HEAT CONTROL RIGHT FRONT AC
D 2 C00225 WINDOW HEAT CONTROL LEFT SIDE AC
E 1 C00224 WINDOW HEAT CONTROL LEFT FRONT AC
E 2 C00227 WINDOW HEAT CONTROL RIGHT SIDE AC
F/O Electrical System Panel, P6-11
Row Col Number Name
ILF 568, 583, 588, 592-596, 671, 672, 832, 836, 837, 841, 842, 968-970, 972, 973, 980-999
B 7 C01650 WINDOW HEAT POWER L3
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
30-41-11
Page 406
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
