F. Access Panels
Number Name/Location
192CL ECS Access Door
G. Install the Ozone Converter
SUBTASK 47-32-02-010-003
(1) Go to the ozone converter [5] location in the left air conditioning bay.
SUBTASK 47-32-02-030-001
(2) Remove the protective covers from the NGS shutoff valve [2] and the air duct [6].
SUBTASK 47-32-02-100-001
(3) Make sure that the ozone converter [5], air duct [6], NGS shutoff valve [2], seals [3], and
couplings [4] are clean, free from grease and unwanted material.
SUBTASK 47-32-02-110-001
(4) To clean the components, do this task: General Cleaning of Metal (Series 80),
TASK 20-30-80-910-801.
SUBTASK 47-32-02-110-002
(5) Prepare these components for an electrical faying surface bond (SWPM 20-20-00):
(a) Mating surfaces of the ozone converter [5].
(b) Mating surface of the NGS shutoff valve [2].
(c) Mating surface of the couplings [4].
SUBTASK 47-32-02-390-001
WARNING
KRYTOX 240AC IS AN AGENT THAT IS POISONOUS AND AN IRRITANT.
MAKE SURE ALL PERSONS OBEY THE PRECAUTIONS WHEN KRYTOX
240AC IS USED.
• DO NOT USE IN AREAS WHERE THERE IS HIGH HEAT, SPARKS, OR
FLAMES.
• CLOSE THE CONTAINER WHEN NOT USED.
• DO NOT GET KRYTOX 240AC IN THE EYES, ON THE SKIN, OR ON YOUR
CLOTHES.
• DO NOT BREATHE THE GAS.
• DO NOT EAT KRYTOX 240AC.
(6) Apply a thin layer of Krytox 240AC perfluoropolyether grease, D50063, grease, D00504, or
lubricant, D00062, on the seals [3].
SUBTASK 47-32-02-430-001
(7) Install the seals [3] in the cavity of the ozone converter [5] on both sides.
SUBTASK 47-32-02-420-001
(8) Do these steps to install the ozone converter [5]:
(a) Put one coupling [4] on each end of the ozone converter [5].
(b) Put the ozone converter [5] in its position
(c) Connect, but do not tighten, the coupling [4] to the ozone converter [5] and the NGS
shutoff valve [2].
(d) Connect, but do not tighten, the coupling [4] on the ozone converter [5] and the air
duct [6].
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-32-02
Page 407
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590,
592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999;
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518,
524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703,
707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
