TASK 53-05-03-210-813
15. INTERNAL - GENERAL VISUAL: FORWARD CARGO COMPARTMENT
(Figure 217)
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
121 Forward Cargo Compartment - Left
122 Forward Cargo Compartment - Right
B. Access Panels
Number Name/Location
S1201 Forward Cargo Compartment Inspection
C. Inspection
SUBTASK 53-05-03-010-011
(1) Open this access panel:
Number Name/Location
S1201 Forward Cargo Compartment Inspection
NOTE: Remove sidewalls and ceiling panels. Remove/displace insulation blankets as
required. Remove/displace auxiliary fuel tank as required (business jet only).
SUBTASK 53-05-03-210-013
(2) Do a General Visual inspection of the forward cargo compartment skin panels including skins,
frames, and stringers (note: inspection includes the circumferential skin and stringer splice at
STA 500E for the -900 models and the circumferential splice at STA 500H for the -800BCF).
SUBTASK 53-05-03-910-015
(3) 737-6789 Basic Task Description, AMM Task 51-05-01-210-808.
SUBTASK 53-05-03-410-011
(4) Close this access panel:
Number Name/Location
S1201 Forward Cargo Compartment Inspection
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-03
Page 249
D633A101-ILF Jun 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
