TASK 24-41-11-400-801
3. External Power Receptacle Installation
(Figure 401)
A. General
(1) The External Power Receptacle is located on the lower right hand side of the airplane. It is
installed forward of the nose gear wheel well.
(2) The External Power Receptacle is part of the pressure seal of the airplane. You must seal the
receptacle when installing it.
B. References
Reference Title
05-51-91-790-801 Cabin Pressure Leak Test (P/B 201)
24-22-00-860-812 Remove Electrical Power (P/B 201)
24-22-00-860-813 Supply External Power (P/B 201)
51-31-00-390-804 Fillet Seal Application (P/B 201)
51-31-00-390-810 Removable Faying (Mated) Surface Seal Application (P/B 201)
C. Consumable Materials
Reference Description Specification
A00247 Sealant - Pressure And Environmental -
Chromate Type
BMS5-95
A02315 Sealant - Low Density, Synthetic Rubber. 2
Part
BMS5-142 Type II
G50365 Agent - Peelable Parting (AC Products -
AC962-73C) Production discontinued, use
stock until depleted.
BAC5000
G50366 Agent - Parting, Peelable, AZ 534-2B (0A3C8 -
Aztec Chemical, Inc., El Monte, CA)
BAC5000, PSD 6-187
G50367 Agent - Peelable Parting (Aztec Chemical AZ
634-2)
MIL-PRF-6799,
BAC5000
G50368 Agent - Peelable Parting (Rexco Chemical
Company - Partall Coverall Film)
BAC5000
G50369 Coating - Alkaline Removable, Water
Resistant
BMS15-12 Type I Class
1
D. Expendables/Parts
AMM Item Description AIPC Reference AIPC Effectivity
1 Receptacle 24-41-11-01-135 ILF 401, 406, 409
24-41-11-01B-080 ILF 405, 410, 416, 424,
425, 427-429, 501-504,
512, 513
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-41-11
Page 407
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 686; ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323,
331-399, 401, 402, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 452, 496,
498-504, 507-510, 512-516, 518-520, 523-528, 530-533, 535-537, 541, 542,
552-557, 560-562, 567-569, 571-577, 581, 583, 585, 671, 672, 703, 707-710,
803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-971, 973 PRE SB 737-24-1198
