MAIN BATTERY CHARGER - ADJUSTMENT/TEST
1. General
A. This procedure contains scheduled maintenance task data.
B. This procedure has this task:
(1) The Main Battery Charger Operational Test.
TASK 24-31-21-710-801
2. Main Battery Charger Operational Test
A. General
(1) The Battery Charger, M5 is located on the E2-1 equipment rack in the main equipment center.
B. References
Reference Title
24-22-00-860-812 Remove Electrical Power (P/B 201)
24-22-00-860-813 Supply External Power (P/B 201)
32-09-00-840-801 Prepare to Put the Airplane in the Air Mode (P/B 201)
32-09-00-860-802 Return the Airplane to the Ground Mode (P/B 201)
C. Location Zones
Zone Area
117 Electrical and Electronics Compartment - Left
118 Electrical and Electronics Compartment - Right
211 Flight Compartment - Left
212 Flight Compartment - Right
D. Access Panels
Number Name/Location
117A Electronic Equipment Access Door
E. Prepare for Test
SUBTASK 24-31-21-860-007
(1) Do this task: Supply External Power, TASK 24-22-00-860-813.
SUBTASK 24-31-21-860-008
(2) Make sure the BUS TRANS switch on the P5-4 panel is in the AUTO position.
SUBTASK 24-31-21-860-009
(3) Make sure the STANDBY POWER switch on the P5-5 panel is in the AUTO position.
SUBTASK 24-31-21-210-001
(4) Make sure the ELEC light on the P5-13 panel is OFF.
(a) To clear ELEC light messages, do this task: P5-13 ELEC Light Message BITE Procedure
(FIM 24-31 TASK 801).
F. Operational Test
SUBTASK 24-31-21-710-003
(1) Do a check of the battery charger per the steps that follow:
(a) Set the GRD PWR switch on the P5-4 panel to the OFF position.
(b) Make sure the BAT switch on the P5-13 panel is set to the ON position.
(c) Set the DC meter selector switch on the P5-13 panel to the BAT position.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-31-21
Page 501
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401,
402, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 452, 491-504, 507-510,
512-516, 518-520, 523-528, 530-533, 535-537, 541, 542, 552-557, 559-564,
567-569, 571-577, 581, 583, 585, 588-590, 592-599, 601-603, 606, 607, 610-615,
620, 625-627, 671, 672, 686, 691-699, 703, 803-813, 821, 822, 831-838, 841, 842,
851, 852, 854-858, 861-863, 871-874, 947, 948, 968-973, 980-999
