(a) Make sure that the float valve is in the fully open position.
(b) Make sure that the float valve moves freely.
(c) Make sure that the float valve is not limited by the adjacent structure.
SUBTASK 47-21-02-700-001
(4) Use a intrinsically safe approved bonding meter, COM-1550, to measure the bonding
resistance between base of the float valve assembly [5] and the vent channel (SWPM
20-20-00).
(a) Make sure the total resistance is 0.010 ohm (10 milliohms) or less.
SUBTASK 47-21-02-390-001
(5) Apply a fillet seal of sealant, A00767, or sealant, A50303, around the float valve assembly [5]
and the adapter [2].
SUBTASK 47-21-02-390-002
(6) Apply cap seal of sealant, A50337, on the screw [4].
SUBTASK 47-21-02-390-003
(7) Manually apply Bonderite M-CR 600 Aero coating, C00862, to exposed surfaces on the base
of the float valve assembly [5].
J. Put the Airplane Back to the Usual Condition
SUBTASK 47-21-02-410-001
(1) Do this task to go out of and close the fuel tank: Center Tank Access Door - Installation,
TASK 28-11-31-400-801.
Close this access panel:
Number Name/Location
631AB Center Tank Access Door - Wing Station 168
END OF TASK
