CONTROL CABIN WINDOW ANTI-ICE SYSTEM - COIL CORD - INSPECTION/CHECK
TASK 30-41-00-200-801
1. Coil Cord - Inspection
(Figure 601)
A. General
(1) This procedure has a task to do an inspection of the No. 2 window coil cord and coil cord
keyway positions.
B. References
Reference Title
20-60-04-100-801 General Visual Inspection of EWIS (P/B 201)
25-11-21-000-801 Flight Compartment Forward Ceiling Panel Removal (P/B 201)
25-11-21-000-805 Flight Compartment Forward Ceiling Panel Removal (P/B 201)
25-11-21-400-801 Flight Compartment Forward Ceiling Panel Installation (P/B 201)
25-11-21-400-805 Flight Compartment Forward Ceiling Panel Installation (P/B 201)
30-41-00-710-801 Window Heat System - Operational Test (P/B 501)
C. Location Zones
Zone Area
211 Flight Compartment - Left
212 Flight Compartment - Right
D. Prepare for the Inspection
SUBTASK 30-41-00-010-001
(1) Get access to the flight compartment.
SUBTASK 30-41-00-860-016
(2) Open these circuit breakers and install safety tags:
CAPT Electrical System Panel, P18-3
Row Col Number Name
D 2 C00225 WINDOW HEAT CONTROL LEFT SIDE AC
E 2 C00227 WINDOW HEAT CONTROL RIGHT SIDE AC
F/O Electrical System Panel, P6-11
Row Col Number Name
B 8 C00393 WINDOW HEAT POWER RIGHT SIDE
F/O Electrical System Panel, P6-12
Row Col Number Name
B 9 C00392 WINDOW HEAT POWER LEFT SIDE
E. Coil Cord Inspection
SUBTASK 30-41-00-020-001
(1) Remove the coil cord from the captain's side of the flight compartment.
SUBTASK 30-41-00-210-002
(2) Examine the position of the captain's sidewall receptacle connector keyway.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
30-41-00
Page 601
D633A101-ILF Oct 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
