SUBTASK 47-21-04-010-009
WARNING
OBEY THE SUBSEQUENT STEPS FOR ACCESS PANELS IDENTIFIED WITH
A NITROGEN GENERATION SYSTEM PLACARD. IF THERE IS A LEAK IN THE
NITROGEN GENERATION SYSTEM, IT WILL DECREASE THE OXYGEN IN
THE AIR THAT YOU BREATHE. IF YOU BREATHE AIR THAT DOES NOT HAVE
SUFFICIENT OXYGEN, DANGEROUS HEALTH CONDITIONS CAN QUICKLY
OCCUR.
(4) Open this access panel:
Number Name/Location
192BL ECS Ram Air Inlet Mixing Duct Panel - Forward
SUBTASK 47-21-04-616-002
(5) Drain fuel from the drain cap (TASK 47-21-00-700-802).
F. Remove the Check Valve
SUBTASK 47-21-04-010-010
WARNING
DO NOT TOUCH THE COMPONENTS OF THE NITROGEN GENERATION
SYSTEM WHEN THEY ARE HOT. WHEN THE COMPONENTS ARE HOT,
THEY CAN CAUSE INJURIES TO PERSONNEL.
WARNING
DO NOT DISCONNECT THE COMPONENTS OF THE NITROGEN
GENERATION SYSTEM, OR DUCTS WHEN THE SYSTEM IS PRESSURIZED.
THE HOT, HIGH-PRESSURE AIR CAN CAUSE INJURIES TO PERSONNEL,
AND DAMAGE TO EQUIPMENT.
CAUTION
MAKE SURE THAT THE MAINTENANCE AREA IS FREE OF CONTAMINATION
FROM SKYDROL, LUBRICANTS, SOLVENTS, FUEL, FUMES, EXHAUST, OR
DUST. DO NOT LET SOLVENTS, LUBRICANTS, OTHER FLUIDS, OR THEIR
FUMES GO INTO THE FLOW PATH TO OR FROM THE AIR SEPARATION
MODULE. CONTAMINATION WILL CAUSE DAMAGE TO THE FIBERS IN THE
AIR SEPARATION MODULE AND DECREASE THEIR LIFE.
(1) Go to the check valve [16] location.
NOTE: The check valve [16] is on the Air Separation Module (ASM [18]) between the drain
cap and the GSE oxygen port tube [14].
SUBTASK 47-21-04-020-003
(2) Do these steps to remove the check valve [16]:
(a) Disconnect the nut [9] from the high flow valve outlet port.
(b) Loosen the two screws [11] that attach the NEADS tube [10] to the ASM [18].
(c) Disconnect the bonding jumper [12] from the NEADS tube [10].
(d) Disconnect the nut [13] from the GSE oxygen port tube [14].
