(a) Make sure that FLIGHT DECK SMOKE1: NOT EVAC (EVAC) shows on the display.
SUBTASK 47-31-02-740-089
(3) Continue to push the down arrow to see all of the menu items for Discrete Input list.
NOTE: For the complete list of discrete input items, refer to Figure 209.
I. Outputs List
SUBTASK 47-31-02-740-090
(1) Push the down/up arrow or the NO button on the I/O Monitor list.
(a) Make sure that Outputs? shows on the display.
SUBTASK 47-31-02-740-091
(2) Push the YES button.
(a) Make sure that RAV Torque Motor CMD: XXX mA shows on the display.
SUBTASK 47-31-02-740-092
(3) Continue to push the down arrow to see all of the menu items for the Outputs list.
SUBTASK 47-31-02-740-093
(4) These are the menu items from the Outputs list:
(a) RAV Torque Motor CMD: XXX mA
(b) NGS SOV SOL CMD: OPEN (CLOSED)
(c) OTSOV SOL CMD: OPEN (CLOSED)
(d) ASM HFV SOL CMD: OPEN (CLOSED)
(e) ASM FBV SOL CMD: NA
(f) NGS FAN REL CMD: NA
(g) NGS RAD REL CMD: NA
SUBTASK 47-31-02-740-094
(5) After you do the necessary maintenance tasks, continue.
J. Outputs List
SUBTASK 47-31-02-740-095
(1) Push the down/up arrow or the NO button on the I/O Monitor list.
(a) Make sure that Oxygen Sensor? shows on the display.
(b) Push the YES button.
SUBTASK 47-31-02-740-096
(2) These are the items from the Oxygen Sensor list:
(a) O2: XX.X%
PO2: YY.YPSIA
(b) O2: OFF
PO2: OFF
(c) O2: WARMING
PO2: WARMING
(d) O2: FAILED
PO2: FAILED
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-31-02
Page 248
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590,
592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999;
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518,
524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703,
707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
