EXTERNAL POWER RECEPTACLE - REMOVAL/INSTALLATION
1. General
A. This procedure has these tasks:
(1) A removal of the External Power receptacle.
(2) An installation of the External Power Receptacle.
TASK 24-41-11-000-801
2. External Power Receptacle Removal
(Figure 401)
A. General
(1) The External Power Receptacle is located on the lower right hand side of the airplane. It is
installed forward of the nose gear wheel well.
B. References
Reference Title
24-22-00-860-812 Remove Electrical Power (P/B 201)
C. Expendables/Parts
AMM Item Description AIPC Reference AIPC Effectivity
1 Receptacle 24-41-11-01-135 ILF 401, 406, 409
24-41-11-01B-080 ILF 405, 410, 416, 424,
425, 427-429, 501-504,
512, 513
24-41-11-01B-275 ILF 101, 151, 156-199,
301, 304, 308, 310, 314,
315, 317-319, 323,
331-399, 402, 451, 452,
496, 498-500, 507-510,
514-516, 518-520,
523-528, 530-533,
535-537, 541, 542,
552-557, 560-562,
567-569, 571-577, 581,
583, 585, 671, 672, 686,
703, 707-710, 804-807,
812, 821, 822, 831, 832,
836, 837, 841, 842, 851,
852, 854-858, 861-863,
871-874, 947, 948,
968-971, 973
24-41-11-02-155 ILF 412
D. Location Zones
Zone Area
116 Nose Landing Gear Wheel Well - Right
E. Access Panels
Number Name/Location
114AR External Power Receptacle Door
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-41-11
Page 401
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 686; ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323,
331-399, 401, 402, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 452, 496,
498-504, 507-510, 512-516, 518-520, 523-528, 530-533, 535-537, 541, 542,
552-557, 560-562, 567-569, 571-577, 581, 583, 585, 671, 672, 703, 707-710,
803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-971, 973 PRE SB 737-24-1198
