(Continued)
Number Name/Location
195CL Wing To Body Fairing - Left Side
195CR Wing To Body Fairings - Right Side
C. Inspection
SUBTASK 53-05-02-010-009
(1) Open these access panels on the Left side:
Number Name/Location
191AL Forward Wing To Body Fairing Panel - Upper
195AL Wing To Body Fairing - Left Side
195BL Wing To Body Fairing - Left Side
195CL Wing To Body Fairing - Left Side
Open these access panels on the Right side:
Number Name/Location
191AR Forward Wing To Body Fairing Panel - Upper
195AR Wing To Body Fairing - Right Side
195BR Wing To Body Fairing - Right Side
195CR Wing To Body Fairings - Right Side
NOTE: Remove or displace aft wing to body fairings as required.
SUBTASK 53-05-02-210-001
(2) Do a General Visual inspection of the skin from Sta 360 to Sta 540 between stringers S-14 to
S-17.
See Doc D626A001-DTR, DTR check form 53-30-02-1 for alternative inspections.
SUBTASK 53-05-02-410-007
(3) Close these access panels on the Left side:
Number Name/Location
191AL Forward Wing To Body Fairing Panel - Upper
195AL Wing To Body Fairing - Left Side
195BL Wing To Body Fairing - Left Side
195CL Wing To Body Fairing - Left Side
Close these access panels on the Right side:
Number Name/Location
191AR Forward Wing To Body Fairing Panel - Upper
195AR Wing To Body Fairing - Right Side
195BR Wing To Body Fairing - Right Side
195CR Wing To Body Fairings - Right Side
END OF TASK
TASK 53-05-02-211-816
42. EXTERNAL - DETAILED: FUSELAGE SIDE SKIN PANELS UNDER THE WING-TO-BODY FAIRING
NOTE: This procedure is a scheduled maintenance task.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-02
Page 221
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
