Boeing 737-600 - Subtask 30-71-00-860-007

(Continued)
Reference Title
25-52-17-000-801 Forward Cargo Compartment Aft Bulkhead Liner - Removal
(P/B 401)
25-52-17-400-801 Forward Cargo Compartment Aft Bulkhead Liner - Installation
(P/B 401)
25-52-19-000-801 Aft Cargo Compartment Aft Bulkhead Liner - Removal (P/B 401)
25-52-19-400-801 Aft Cargo Compartment Aft Bulkhead Liner - Installation
(P/B 401)
25-52-20-000-801 Waste Tank Enclosure Panel - Removal (P/B 401)
25-52-20-400-801 Waste Tank Enclosure Panel - Installation (P/B 401)
SSM 30-71-11 System Schematics Manual
WDM 30-71-11 Wiring Diagram Manual
B. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
COM-1572 Thermometer - Infrared, Intrinsically Safe
737-600, -700, -800
Part #: 568 Ex Supplier: 89536
Opt Part #: DHS24XC-FM Supplier: 08086
Opt Part #: DHS24XF-FM Supplier: 08086
Opt Part #: EX-MP4 A Supplier: 3GT36
Opt Part #: IR-16L3 IS Supplier: 75037
COM-2531 Clamp-On- Current Meter
737-600, -700, -800
Part #: 324 Supplier: 89536
Part #: I800 Supplier: 89536
Part #: LH41A Supplier: 89536
Opt Part #: 321 Supplier: 89536
Opt Part #: 322 Supplier: 89536
Opt Part #: 80I-600A Supplier: 89536
Opt Part #: MODEL 33 Supplier: 89536
Opt Part #: MODEL 36 Supplier: 89536
C. Consumable Materials
Reference Description Specification
G02319 Spray - Freeze - Miller-Stephenson MS-242N
G02320 Ice - Crushed
D. Location Zones
Zone Area
143 Area Below Aft Cargo Compartment - Left
E. Prepare for the Procedure
SUBTASK 30-71-00-860-007
(1) Do this task: Supply External Power, TASK 24-22-00-860-813.
F. Procedure
NOTE: You should not feel the heater as a procedure to measure for heat.
