TASK 53-51-21-000-801
6. Aft Wing-To-Body Fairing Panel Removal
(Figure 403)
A. References
Reference Title
28-25-07-020-801 APU Fuel Feed Line Shroud Drain Mast Removal (P/B 401)
34-32-11-000-801 Marker Beacon Antenna Removal (P/B 401)
34-32-11-000-802 Marker Beacon Antenna with Gasket - Removal (P/B 401)
51-31-00-160-801 Prepare For Sealing (P/B 201)
B. Location Zones
Zone Area
194 Lower Wing-To-Body Fairing - Aft of Wheel Well
C. Access Panels
Number Name/Location
194AL Aft Wing To Body Fairing Panel
194AR Aft Wing To Body Fairing Panel
194BL Flap Track Lubrication Panel - Aft
194BR Flap Track Lubrication Panel - Aft
194CL Aft Wing To Body Fairing Panel
194CR Aft Wing To Body Fairing Panel
194DL Aft Wing To Body Fairing Panel
194DR Aft Wing To Body Fairing Panel
194E Aft Wing To Body Fairing Panel
194FL Aft Wing To Body Fairing Panel
194FR Aft Wing To Body Fairing Panel
194GL Aft Wing To Body Fairing Panel
194GR Aft Wing To Body Fairing Panel
194HL Aft Wing To Body Fairing Panel
194HR Aft Wing To Body Fairing Panel
D. Prepare for Aft Wing-To-Body Fairing Panels Removal Procedure
SUBTASK 53-51-21-020-007
(1) If necessary, remove or disconnect the equipment that is attached to the fairing.
(a) For the marker beacon antenna, do this task: Marker Beacon Antenna Removal,
TASK 34-32-11-000-801.
(b) For the marker beacon antenna, do this task: Marker Beacon Antenna with Gasket -
Removal, TASK 34-32-11-000-802
(c) For the APU Drain Mast, do this task: APU Fuel Feed Line Shroud Drain Mast Removal,
TASK 28-25-07-020-801.
E. Aft Wing-To-Body Fairing Panels Removal Procedure
SUBTASK 53-51-21-020-001
(1) Remove sealant from the edge of the applicable panel.
NOTE: You can remove a section of the fillet seal (TASK 51-31-00-160-801).
