TASK 47-31-02-400-801
3. BITE Display Unit Installation
(Figure 401)
A. References
Reference Title
20-30-80-910-801 General Cleaning of Metal (Series 80) (P/B 201)
47-00-00-800-801 Ground Operation of the Nitrogen Generation System (P/B 201)
51-21-41-370-802 Bonderite M-CR 600 Aero, Bonderite M-CR Alcrm 1200 Aero or
Bonderite M-CR 1200S Aero Application Process (P/B 701)
SWPM 20-20-10 Standard Wiring Practices Manual
B. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
COM-1550 Bonding Meters - Approved, Intrinsically Safe (Approved for use in
Class I, Divisions I & II hazardous (classified) locations. Outside
these hazardous locations, COM-614 can be used in lieu of
COM-1550).
737-600, -700, -800
Part #: 620LK Supplier: 1CRL2
Part #: M1 Supplier: 3AD17
Part #: T477W (C15292) Supplier: 01014
Opt Part #: M1B Supplier: 3AD17
C. Consumable Materials
Reference Description Specification
C00862 Coating - Chemical Conversion - Bonderite
M-CR 600 Aero (Formerly Alodine 600)
D. Expendables/Parts
AMM Item Description AIPC Reference AIPC Effectivity
1 BITE Display Unit 47-31-02-01A-150 ILF 402, 451, 452, 503,
504, 508-510, 514, 516,
523-528, 541, 568, 569,
573-577, 581, 583, 585,
588-590, 592-599,
601-603, 606, 607,
610-615, 620, 625-627,
691-699, 832-835, 838,
854, 856, 971, 980-999
E. Location Zones
Zone Area
132 Center Section Wing Box, Body Station 540.00 to Body Station 663.75 - Right
212 Flight Compartment - Right
F. Access Panels
Number Name/Location
192CR ECS Access Door
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-31-02
Page 405
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590,
592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999;
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518,
524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703,
707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
