SUBTASK 24-34-00-860-010
(1) Make sure that these circuit breakers are open and have safety tags:
Battery Shield, J9
Row Col Number Name
A 4 C00142 BATTERY CHARGER
A 5 C01340 BATTERY BUS
SUBTASK 24-34-00-710-003
(2) Do the following steps at the P5–5 panel:
(a) Make sure the STANDBY POWER switch on the P5-5 panel is in the AUTO position.
(b) Make sure the STANDBY PWR OFF light on the P5-5 panel is off.
(c) Set both the AC meter selector switch and the DC meter selector switch on the P5-13
panel to the STBY PWR position.
(d) Make sure the AC meter shows no values.
(e) Make sure the DC meter shows no values
(f) Set the STANDBY POWER switch to the OFF position.
(g) Make sure the STANDBY POWER OFF light does not come on.
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-34-00
Page 202
D633A101-ILF Feb 15/2015
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
