STATIC INVERTER REMOTE CONTROL CIRCUIT BREAKER (RCCB) - REMOVAL/INSTALLATION
1. General
A. This procedure has these tasks:
(1) Static Inverter RCCB Removal
(2) Static Inverter RCCB Installation.
TASK 24-34-31-000-801-001
2. Static Inverter RCCB Removal
(Figure 401, Figure 402)
A. General
(1) The Static Inverter RCCB, C1341, is located on the J9 Battery Shield in the Main Equipment
Center.
B. References
Reference Title
SWPM 20-83-00 Standard Wiring Practices Manual
C. Location Zones
Zone Area
117 Electrical and Electronics Compartment - Left
121 Forward Cargo Compartment - Left
122 Forward Cargo Compartment - Right
D. Access Panels
Number Name/Location
117A Electronic Equipment Access Door
E. Prepare for the Removal
SUBTASK 24-34-31-860-001-001
(1) Set the STANDBY POWER switch on the P5-5 panel to the OFF position and attach a
DO-NOT-OPERATE tag to it.
SUBTASK 24-34-31-860-002-001
(2) Set the BAT switch on the P5-13 panel to the OFF position and attach a DO-NOT-OPERATE
tag to it.
SUBTASK 24-34-31-010-001-001
(3) Open this access panel:
Number Name/Location
117A Electronic Equipment Access Door
ILF 562, 588, 592-596, 833, 834
(a) Remove the access cover on top of the J39 shield to get access to the circuit breakers.
ILF 562, 588, 592-596, 686, 707-710, 833, 834, 854-856, 861-863, 871-874
(b) Open these circuit breakers and install safety tags:
Battery Shield, J9
Row Col Number Name
A 4 C00142 BATTERY CHARGER
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-34-31
Config 1
Page 401
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 562, 588, 592-596, 686, 707-710, 833, 834,
854-856, 861-863, 871-874
To Next Page
