TASK 24-31-11-400-801-001
3. Battery Installation
(Figure 401)
NOTE: This procedure is a scheduled maintenance task.
A. General
(1) The M6 Battery is located below the E3 equipment rack in the main equipment area.
(2) The battery is removed and installed in the forward cargo area. The circuit breakers on the J9
panel are installed in the main equipment center.
B. References
Reference Title
20-30-51-910-801 Miscellaneous Materials (P/B 201)
24-22-00-860-812 Remove Electrical Power (P/B 201)
24-22-00-860-813 Supply External Power (P/B 201)
FIM 24-31 TASK 801 P5-13 ELEC Light Message BITE Procedure
C. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-1633 Equipment - Battery Installation
737-700, -800
Part #: C24003-1 Supplier: 81205
D. Consumable Materials
Reference Description Specification
G02479 Lockwire - MS20995CY20, Copper - 0.020
Inch (0.508 mm) Diameter
NASM20995
E. Expendables/Parts
AMM Item Description AIPC Reference AIPC Effectivity
1 Battery 24-31-11-01-005 ILF 707-710
24-31-11-01-007 ILF 686, 854-856,
861-863, 871-874
24-31-11-02-005 ILF 562, 588, 592-596,
833, 834
F. Location Zones
Zone Area
117 Electrical and Electronics Compartment - Left
118 Electrical and Electronics Compartment - Right
121 Forward Cargo Compartment - Left
122 Forward Cargo Compartment - Right
211 Flight Compartment - Left
212 Flight Compartment - Right
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-31-11
Config 1
Page 408
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 562, 588, 592-596, 686, 707-710, 833, 834,
854-856, 861-863, 871-874
