(e) Make sure the ozone converter [5] is aligned with the NGS shutoff valve [2] and the air
duct [6].
(f) Tighten the two couplings [4] to 62.5 ±7.5 in-lb (7.1 ±0.8 N·m).
SUBTASK 47-32-02-765-001
(9) Use the intrinsically safe approved bonding meter, COM-1550, to measure the resistance
between the 41 beam and the ozone converter [5] (SWPM 20-20-00).
ILF 568, 569, 581, 583, 585, 588-590, 592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699,
833-835, 838, 980-999
(a) Make sure the resistance is 0.010 ohm (10 milliohms) or less.
ILF 402, 452, 509, 510, 523, 525-528, 576, 577, 971; ILF 101, 151, 156-199, 301, 304, 308, 310, 314,
315, 317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507,
508, 512-514, 516, 518, 524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672,
686, 703, 707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
(b) Make sure that the resistance is 0.008 ohm (8 milliohms) or less.
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590, 592-599, 601-603,
606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999; ILF 101, 151, 156-199, 301,
304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429,
451, 501-504, 507, 508, 512-514, 516, 518, 524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567,
571-575, 671, 672, 686, 703, 707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852,
854-858, 861-863, 871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
H. Operational Test of the Ozone Converter
SUBTASK 47-32-02-710-001
(1) Remove the safety tags and close these circuit breakers:
CAPT Electrical System Panel, P18-3
Row Col Number Name
ILF 402, 452, 509, 510, 523, 525-528, 576, 577, 971; ILF 101, 151, 156-199, 301, 304, 308, 310, 314,
315, 317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507,
508, 512-514, 516, 518, 524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672,
686, 703, 707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
D 17 C01657 NITROGEN GEN CONT
ILF 568, 569, 581, 583, 585, 588-590, 592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699,
833-835, 838, 980-999; ILF 567, 973 POST SB 737-47-1003
D 17 C01657 NITROGEN GENERATION CONTROL
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590, 592-599, 601-603,
606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999; ILF 101, 151, 156-199, 301,
304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429,
451, 501-504, 507, 508, 512-514, 516, 518, 524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567,
571-575, 671, 672, 686, 703, 707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852,
854-858, 861-863, 871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
E 15 C01680 NGS ALT PWR
SUBTASK 47-32-02-860-002
(2) Remove the DO-NOT-OPERATE tags from the L PACK and R PACK selector switches, on the
P5-10 air conditioning panel.
(a) Put the L PACK and R PACK selector switches to the AUTO position.
SUBTASK 47-32-02-790-001
(3) Do this task: Leak Check of the Nitrogen Generation System, TASK 47-00-00-790-801.
(a) Repair the leaks that you find.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-32-02
Page 408
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590,
592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999;
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518,
524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703,
707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
