WING-TO-BODY FAIRING BLOWOUT PANEL - REMOVAL/INSTALLATION
1. General
A. This procedure contains two tasks. The first task is the removal of the blowout panel for the wing-to-
body fairing. The second task is the installation of the blowout panel for the wing-to-body fairing.
B. The blowout panels have a hinge on one side. The rivets that go through the clips on the other side
hold the blowout panels closed.
TASK 53-51-11-000-801
2. Blowout Panel for the Wing-to-Body Fairing Removal
A. Location Zones
Zone Area
200 Upper Half of Fuselage
B. Procedure
SUBTASK 53-51-11-010-001
(1) If the panel blows out, open the underwing fairing and remove the rivets.
END OF TASK
TASK 53-51-11-400-801
3. Blowout Panel for the Wing-to-Body Fairing Installation
A. References
Reference Title
51-21-81 P/B 701 ABRASION-RESISTANT TEFLON FINISH -
CLEANING/PAINTING
51-31-00-390-801 Non-Removable Faying (Mated) Surface Seal Application
(P/B 201)
B. Tools/Equipment
Reference Description
STD-810
Spatula - Fillet Smoothing, Hardwood or Plastic
C. Location Zones
Zone Area
200 Upper Half of Fuselage
D. Procedure
SUBTASK 53-51-11-210-001
(1) Examine the attach clips for damage.
SUBTASK 53-51-11-140-003
(2) Use a hardwood or plastic fillet smoothing spatula, STD-810 to clean the sealant from the
mating surfaces.
SUBTASK 53-51-11-120-002
(3) Apply an abrasion resistant finish and parting agent to the outer face of the fairing lip
(ABRASION-RESISTANT TEFLON FINISH - CLEANING/PAINTING,
PAGEBLOCK 51-21-81/701).
SUBTASK 53-51-11-140-004
(4) Remove the sealant from the clearance between the blowout panel and panel cutout.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-51-11
Page 401
D633A101-ILF Feb 15/2015
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
