(Continued)
Reference Description
SPL-768 Sealant Removal Tool, Non-Metallic
737-600, -700, -800
Part #: ST982L-9 Supplier: 81205
Part #: ST982LF-9 Supplier: 62176
Part #: ST982LH-A-1 Supplier: 62176
C. Consumable Materials
Reference Description Specification
A50337 Sealant - Fuel Tank BMS5-45 Class B
D50063 Grease - Perfluoropolyether, fuel and oxygen
resistant - Krytox 240AC
MIL-PRF- 27617 Type III
D. Expendables/Parts
AMM Item Description AIPC Reference AIPC Effectivity
1 High flow valve 47-11-01-01-155 ILF 402, 451, 452, 503,
504, 508-510, 514, 516,
523-528, 541, 568, 569,
573-577, 581, 583, 585,
588-590, 592-599,
601-603, 606, 607,
610-615, 620, 625-627,
691-699, 832-835, 838,
854, 856, 971, 980-999
9 O-ring 47-11-01-01-150 ILF 402, 451, 452, 503,
504, 508-510, 514, 516,
523-528, 541, 568, 569,
573-577, 581, 583, 585,
588-590, 592-599,
601-603, 606, 607,
610-615, 620, 625-627,
691-699, 832-835, 838,
854, 856, 971, 980-999
E. Location Zones
Zone Area
131 Center Section Wing Box, Body Station 540.00 to Body Station 663.75 - Left
211 Flight Compartment - Left
212 Flight Compartment - Right
F. Access Panels
Number Name/Location
192BL ECS Ram Air Inlet Mixing Duct Panel - Forward
G. Prepare to Install the High Flow Valve
SUBTASK 47-11-02-000-002
(1) Go to the high flow valve [1] location.
NOTE: The high flow valve [1] is attached to the forward strap bracket [12] that holds the
ASM [8] in its position.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-11-02
Page 407
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590,
592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999;
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518,
524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703,
707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
