ILF ALL; AUTOTHROTTLE SWITCHPACK WITH INTEGRATED SWITCHES P/N 254A1150-11, -12,
-13, -14, -15, -16
(h) If any switches are still not in the specified limits, replace the switchpack.
1) These are the tasks: Autothrottle Switchpack Assembly - Removal,
TASK 76-11-07-020-802-F00 and Autothrottle Switchpack Assembly - Installation,
TASK 76-11-07-400-802-F00
ILF ALL; AUTOTHROTTLE SWITCHPACK WITH REPLACEABLE SWITCHES P/N 254A1150-1, -2, -7,
-8, -9, -10
(i) If any switches are still not in the specified limits, then do the Switch Adjustment that
follows:
ILF ALL
SUBTASK 76-11-07-710-013-F00
(4) Do these steps to check the applicable switch in the right switchpack:
(a) Insert a rod under the right reverse thrust interlock solenoid latch.
1) Move the latch up off of the autothrottle brake cam.
(b) Mechanically restrain the rod to hold the right interlock solenoid off the autothrottle brake
cam.
NOTE: This will let the brake housing turn and not be limited by the solenoid.
(c) Move the right thrust lever and reverse thrust lever until the TRA value that shows on the
CDU is in the range shown in the table below (Table 502):
NOTE: The forward mechanical stop (full forward thrust) is at 84 +/-1 degrees TRA, the
idle stop is at 36 +/-0.25 degrees TRA, and the aft mechanical stop (full reverse
thrust) is at 6 +/-1 degrees TRA.
(d) Do a continuity check at the applicable switch connector.
Table 502/76-11-07-993-811-F00
SWITCH CONNECTOR PINS TRA VALUE CONDITION TRANSITION
S1 D11132P 1-2 8.00-42.00
46.00-82.00
Open
Closed
44.00±2.0
2-3 8.00-42.00
46.00-82.08
Closed
Open
S2 D11134P 1-2 8.00-42.00
46.00-82.00
Not Used
44.00±2.0
2-3 8.00-42.00
46.00-82.00
Closed
Open
S3 D11134P 4-5 8.00-42.00
46.00-82.00
Not Used
44.00±2.0
5-6 8.00-42.00
46.00-82.00
Closed
Open
S4 D11132P 14-7 8.00-30.00
34.00-82.00
Closed
Open
32.00±2.0
7-8 8.00-30.00
34.00-82.00
Open
Closed
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-07
Page 506
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
