TASK 53-05-02-130-818
43. EXTERNAL - SPECIAL DETAILED: SKIN UNDER UPPER WING-TO-BODY DRAG ANGLE
A. Location Zones
Zone Area
125 Air Conditioning Distribution Bay - Left
126 Air Conditioning Distribution Bay - Right
191 Lower Wing-To-Body Fairing - Forward of Wing Box
B. Access Panels
Number Name/Location
191AL Forward Wing To Body Fairing Panel - Upper
191AR Forward Wing To Body Fairing Panel - Upper
C. Inspection
SUBTASK 53-05-02-010-216
(1) Open these access panels:
Number Name/Location
191AL Forward Wing To Body Fairing Panel - Upper
191AR Forward Wing To Body Fairing Panel - Upper
SUBTASK 53-05-02-130-018
(2) Do an Ultrasonic inspection of the skin under the upper wing-to-body drag angle along the
upper drag angle forward of Station 536 between S-21 and S-22.
See Doc D626A001-DTR, DTR check form 53-30-02-5 for alternative inspections.
The NDI method(s) necessary to accomplish the intent of this inspection is contained in the
737 Nondestructive Test Manual (D6-37239). The inspection procedures are contained in Part
4, 53-20-02.
SUBTASK 53-05-02-410-212
(3) Close these access panels:
Number Name/Location
191AL Forward Wing To Body Fairing Panel - Upper
191AR Forward Wing To Body Fairing Panel - Upper
END OF TASK
ILF ALL
TASK 53-05-02-250-826
44. EXTERNAL - SPECIAL DETAILED: LONGITUDINAL LAP SPLICE
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
231 Forward Passenger Compartment - Forward Entry Door to Sta 663.75 - Left
