TASK 47-31-02-740-805
6. Other Function Menu
(Figure 209)
A. General
(1) This task gives the instructions to operate the BDU control panel for the OTHER FUNCTION
menu.
(2) To help you move through the BDU OTHER FUNCTION menu structure, refer to Figure 209.
(3) The OTHER FUNCTION menu lets you do a check of the NGS system configuration. The
OTHER FUNCTION menu also lets you monitor the input signals and the condition of the NGS
controller valve drivers.
B. Access Panels
Number Name/Location
192CR ECS Access Door
192DR ECS High Pressure Access Door
C. Main Menu
SUBTASK 47-31-02-740-052
(1) Do this task: BDU Main Menu, TASK 47-31-02-740-801.
(a) Push the BDU control panel up or down arrows or the NO button until Other Functions?
shows on the display.
D. Other Function List
SUBTASK 47-31-02-740-053
(1) Make sure that Other Functions? shows on the display.
(a) Push the YES button.
1) Make sure that System Config? shows on the display.
SUBTASK 47-31-02-740-077
(2) These are the menu items from the Other Function list:
(a) System Config?
(b) I/O Monitor?
SUBTASK 47-31-02-740-078
(3) Push the up and down arrows or NO button to get to the applicable Other Function menu item.
E. System Configuration List
SUBTASK 47-31-02-740-054
(1) Make sure that SYSTEM CONFIG? shows on the display.
(a) Push the YES button.
1) Make sure that HARDWARE PART NO: shows on the display.
SUBTASK 47-31-02-740-079
(2) These are the menu items from the System Configuration list:
(a) HARDWARE PART NO:
(b) BOOT LOADER PART NO:
(c) SOFTWARE PART NO:
(d) CONFIG PART NO:
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-31-02
Page 246
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590,
592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999;
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518,
524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703,
707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
