THRUST LEVER ANGLE RESOLVER AND AUTOTHROTTLE BRAKE ASSEMBLY - REMOVAL/
INSTALLATION
1. General
A. This procedure has two tasks:
(1) Thrust Lever Angle Resolver and Autothrottle Brake Assembly Removal
(2) Thrust Lever Angle Resolver and Autothrottle Brake Assembly Installation.
TASK 76-11-05-000-801-F00
2. Thrust Lever Angle Resolver and Autothrottle Brake Assembly Removal
(Figure 401, Figure 402 and Figure 403)
A. General
(1) This task provides the instructions on how to remove the thrust lever angle resolver and
autothrottle brake assembly.
(2) The thrust lever angle resolver is referred to as the resolver.
(3) The autothrottle brake assembly is referred to as the brake assembly.
(4) The resolvers and brake assemblies can be found forward of the nose wheel well, below the
flight compartment floor.
(5) There is one resolver installed on each of the engine 1 and engine 2 autothrottle assemblies.
(6) There is one brake assembly installed on each of the engine 1 and engine 2 autothrottle
assemblies.
B. References
Reference Title
22-31-91-020-801 Autothrottle Servo Motor and Gearbox Removal (P/B 401)
C. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-2414 Tool Set - Auto Throttle Servo Assembly
737-600, -700, -800
Part #: J22001-1 Supplier: 81205
D. Location Zones
Zone Area
112 Area Forward of Nose Landing Gear Wheel Well
113 Area Above and Outboard of Nose Landing Gear Wheel Well - Left
114 Area Above and Outboard of Nose Landing Gear Wheel Well - Right
211 Flight Compartment - Left
212 Flight Compartment - Right
E. Access Panels
Number Name/Location
112A Forward Access Door
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-05
Page 401
D633A101-ILF Oct 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
