RAM AIR VALVE - REMOVAL/INSTALLATION
1. General
A. This procedure has these tasks:
(1) Ram Air Valve Removal
(2) Ram Air Valve Installation
TASK 47-32-05-000-801
2. Ram Air Valve Removal
(Figure 401)
A. References
Reference Title
36-00-00-860-806 Remove Pressure from the Pneumatic System (P/B 201)
47-00-00-010-801 Nitrogen Generation System (NGS) Precautions (P/B 201)
47-11-01-000-801 Air Separation Module (ASM) Removal (P/B 401)
B. Location Zones
Zone Area
131 Center Section Wing Box, Body Station 540.00 to Body Station 663.75 - Left
212 Flight Compartment - Right
C. Access Panels
Number Name/Location
192BL ECS Ram Air Inlet Mixing Duct Panel - Forward
D. Prepare for the Removal
SUBTASK 47-32-05-864-001
(1) Do this task: Remove Pressure from the Pneumatic System, TASK 36-00-00-860-806.
(a) Make sure that the dual duct pressure gage shows 0.50 psig (3.45 kPa) or less in the L
and R pneumatic ducts.
SUBTASK 47-32-05-860-001
(2) Put the L PACK and R PACK selector switches, on the P5-10 air conditioning panel, to the OFF
position.
(a) Put DO-NOT-OPERATE tags on the L PACK and R PACK selector switches.
SUBTASK 47-32-05-865-001
(3) Open these circuit breakers and install safety tags:
CAPT Electrical System Panel, P18-3
Row Col Number Name
ILF 402, 452, 509, 510, 523, 525-528, 576, 577, 971; ILF 101, 151, 156-199, 301, 304, 308, 310, 314,
315, 317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507,
508, 512-514, 516, 518, 524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672,
686, 703, 707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
D 17 C01657 NITROGEN GEN CONT
ILF 568, 569, 581, 583, 585, 588-590, 592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699,
833-835, 838, 980-999; ILF 567, 973 POST SB 737-47-1003
D 17 C01657 NITROGEN GENERATION CONTROL
