ILF ALL
TASK 53-05-03-210-835
46. INTERNAL - GENERAL VISUAL: PASSENGER COMPARTMENT FLOOR STRUCTURE - WET AREA
(Figure 252)
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
221 Passenger Compartment - Aft of Control Compartment to Forward Entry Door - Left
222 Passenger Compartment - Aft of Control Compartment to Forward Entry Door -
Right
231 Forward Passenger Compartment - Forward Entry Door to Sta 663.75 - Left
232 Forward Passenger Compartment - Forward Entry Door to Sta 663.75 - Right
241 Aft Passenger Compartment - Station 663.75 to Aft Pressure Bulkhead - Left
242 Aft Passenger Compartment - Station 663.75 to Aft Pressure Bulkhead - Right
B. Access Panels
Number Name/Location
S2004 Passenger Compartment Floor Structure - Wet Area Inspection
C. Inspection
SUBTASK 53-05-03-010-032
(1) Special Access:
Number Name/Location
S2004 Passenger Compartment Floor Structure - Wet Area Inspection
NOTE: Galleys and lavs removal is not required. Remove galley kick-plates and any other
easily removable panels that may help inspect areas under galleys and lavs.
SUBTASK 53-05-03-210-035
(2) Do a General Visual inspection of the galley and lav attach fittings and any other easily visible
portions of the floor structure in wet area (within approximately 20 inches from galleys and
lavs, and the floor structure below the door to, and including, the door side of the first frame
from the door in both the forward and aft directions).
SUBTASK 53-05-03-910-049
(3) 737-6789 Basic Task Description, AMM Task 51-05-01-210-804.
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-03
Page 298.52
D633A101-ILF Jun 15/2015
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
