(WARNING PRECEDES)
WARNING
DO NOT DISCONNECT THE COMPONENTS OF THE NITROGEN
GENERATION SYSTEM, OR DUCTS WHEN THE SYSTEM IS PRESSURIZED.
THE HOT, HIGH-PRESSURE AIR CAN CAUSE INJURIES TO PERSONNEL,
AND DAMAGE TO EQUIPMENT.
(1) Obey the Nitrogen Generation System (NGS) precautions (TASK 47-00-00-010-801).
D. Remove the Lower Lightning Shield
SUBTASK 47-21-08-030-001
(1) Go into the left wheel well.
(a) Go to the lower lightning shield [5] location.
NOTE: The lower lightning shield [5] is on the rear spar.
SUBTASK 47-21-08-030-002
(2) Do these steps to remove the lower lightning shield [5].
(a) Remove two cap screws [6], four washers [7], and two nuts [8] that attach the lower
lightning shield [5] to the attach bracket.
NOTE: Keep the fasteners for installation.
(b) Remove the screw [9], two washers [7], and nut [8] that attach the lower lightning
shield [5] to the hydraulic bracket.
NOTE: Keep the fasteners for installation.
(c) Remove two cap screws [12], four washers [7], two spacers [10], and two nuts [8] from
the two clamps [11] that attach the lower lightning shield [5] to the NEADS tube [13].
NOTE: Keep the fasteners for installation.
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-21-08
Page 410
D633A101-ILF Oct 15/2019
