(a) Remove the bolts that attach the hinge arms to the hinge fittings on the radome and
remove the radome from the fuselage.
NOTE: When you remove the bolts, prepare to catch the shims that are installed
between the hinge arms and the hinge fittings. Look at the installed positions of
the shims to help the installation of the same radome.
END OF TASK
TASK 53-52-00-400-801
3. Nose Radome Installation
(Figure 401)
A. References
Reference Title
20-30-89-910-801 Final Cleaning of Solvent Sensitive Organic Coatings Prior to
Non-structural Bonding (Series 89) (P/B 201)
B. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
COM-614 Bonding Meters - Non-Intrinsically Safe (For use in outside Class I,
Divisions I & II non-hazardous locations. For hazardous locations,
use COM-1550).
737-600, -700, -800
Part #: 247000 Supplier: 00426
Part #: 620LK Supplier: 1CRL2
Part #: M1 Supplier: 3AD17
Part #: T477W (C15292) Supplier: 01014
Opt Part #: 247001 Supplier: 00426
Opt Part #: M1B Supplier: 3AD17
COM-1550 Bonding Meters - Approved, Intrinsically Safe (Approved for use in
Class I, Divisions I & II hazardous (classified) locations. Outside
these hazardous locations, COM-614 can be used in lieu of
COM-1550).
737-600, -700, -800
Part #: 620LK Supplier: 1CRL2
Part #: M1 Supplier: 3AD17
Part #: T477W (C15292) Supplier: 01014
Opt Part #: M1B Supplier: 3AD17
C. Consumable Materials
Reference Description Specification
A00281 Adhesive - Dow Corning 3145 RTV MIL-A-46146 (BAC5010
Type 79)
A00335 Adhesive - Silicone Rubber, 2 Part, RTV BAC5010 Type 68
B00065 Alcohol - Denatured, Ethyl (Ethanol) AMS 3002 (Supersedes
O-A-396)
B00148 Solvent - Methyl Ethyl Ketone (MEK) ASTM D740
B01009 Solvent - Final Cleaning Of All Organic Ctgs
Before Non-Structural Bonding - Series 89
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-52-00
Page 402
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
