SUBTASK 53-31-31-420-018
(26) On the upper seal only, manually put the leading edge of the stabilizer to the full up position.
SUBTASK 53-31-31-210-004
(27) Make sure that the double flush rivet at the uppermost corner of the seal plates is not out more
than 0.003 in. (0.076 mm).
NOTE: If the rivet touches the body structure, cut the driven head until it does not touch the
body structure.
E. Put the Airplane to Its Usual Condition
SUBTASK 53-31-31-020-011
(1) Remove all the protective tapes and the covers.
SUBTASK 53-31-31-160-001
(2) Clean up the area.
SUBTASK 53-31-31-420-019
(3) Install the center track strips [3].
SUBTASK 53-31-31-080-006-001
(4) Remove the lock, SPL-1672 from the stabilizer trim wheel at the control stand.
SUBTASK 53-31-31-860-044-001
(5) Set the stabilizer trim cutout switches to the NORMAL position.
SUBTASK 53-31-31-860-045-001
(6) Remove the safety tags and close these circuit breakers:
CAPT Electrical System Panel, P18-1
Row Col Number Name
C 2 C00849 AFCS STABILIZER TRIM
CAPT Electrical System Panel, P18-2
Row Col Number Name
C 8 C00544 FLIGHT RECORDER POSITION SENSOR
CAPT Electrical System Panel, P18-3
Row Col Number Name
A 15 C00644 EXTERIOR LIGHTING LOGO ILLUM
F/O Electrical System Panel, P6-2
Row Col Number Name
B 10 C00207 FLIGHT CONTROL STAB TRIM CONT
D 10 C00840 FLIGHT CONTROL STAB TRIM ACTUATOR
END OF TASK
