(d) Push the YES button.
1) The shop details list shows.
SUBTASK 47-31-02-740-063
(2) These are the menu items for the shop details list:
(a) SHOP CODE: XXXX
(b) NGS STATE: NGS ON (NGS OFF, NGS STARTBIT, NGS IBIT, NGS COOLDOWN)
(c) IBIT STATE: ELECTRICAL (SYSTEM, NGS PERF LO FLOW, NGS PERF HI FLOW,
OFF)
(d) AIRCRAFT STATE: GROUND (CLIMB, CRUISE, DESCENT, IN AIR)
(e) ASM STATE: ASM LOW (ASM MID1, ASM MID2, ASM HIGH, ASM IBIT)
(f) TASMI 1: SXXX F
TASMI 2: SYYYF
(g) DPHI: SXXX.X psid
DPMID: NA
(h) PALT: XXXXX ft
PB: SYYY.Y psig
(i) RAV T/M
I:XXXXmA V:YY.YV
(j) NGS SOV SOL
I:XXXXmA V:YY.YV
(k) OTSOV SOL
I:XXXXmA V:YY.YV
(l) ASM HFV SOL
I:XXXXmA V:YY.YV
(m) ASM FBV SOL: NA
(n) NGS FAN REL: NA
(o) NGS RAD REL: NA
SUBTASK 47-31-02-740-024
(3) Use the up and down arrows to see all the menu items for the shop details list.
SUBTASK 47-31-02-740-025
(4) After you do the necessary maintenance tasks, continue.
I. Put the Airplane Back to the Usual Condition
SUBTASK 47-31-02-740-026
(1) Make sure all BDU initiated tests are complete.
(a) Push the ON/OFF button.
SUBTASK 47-31-02-410-003
(2) Close this access panel:
Number Name/Location
192CR ECS Access Door
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-31-02
Page 212
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590,
592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999;
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518,
524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703,
707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
