(b) Connect the hose of the adapter to the pressurized oil source dispenser, STD-4051.
(c) Fill the starter with 10.1-16.9 fluid ounces (300-500 cc) of oil, D00599 [CP2442].
1) Use the same type of engine oil as in the engine accessory gearbox.
NOTE: The accessory gearbox supplies engine oil to the starter.
(d) Remove the adapter from the magnetic plug housing.
SUBTASK 80-11-01-420-008-F00
(3) Install the magnetic plug [2] as follows:
(a) If not already done, remove and discard the old packings [1].
(b) Apply clean oil, D00599 [CP2442] to the two new packings [1].
(c) Install the packings [1] on the magnetic plug [2].
(d) Put the magnetic plug [2] in the magnetic plug housing and align the bayonet pins with
the slots.
(e) Push the magnetic plug [2] until the pins touch the bottom of the slots and turn the plug
clockwise until it locks.
I. Starter Servicing (Alternate Method)
SUBTASK 80-11-01-610-003-F00
WARNING
DO NOT LET OIL STAY ON YOUR SKIN. YOU CAN ABSORB POISONOUS
MATERIALS FROM THE OIL THROUGH YOUR SKIN.
(1) Gravity fill the starter with oil, D00599 [CP2442] as follows:
NOTE: Fill the oil to the starter before you install the starter.
(a) Remove the magnetic plug housing (TASK 80-11-01-360-801-F00).
(b) Fill the starter with 10.1-16.9 fluid ounces (300-500 cc) of oil, D00599 [CP2442] as
follows:
1) Use the same type of engine oil as in the engine accessory gearbox.
NOTE: The accessory gearbox supplies engine oil to the starter.
(c) Install the magnetic plug housing with a new packing (TASK 80-11-01-360-801-F00).
(d) Continue with the starter installation steps (TASK 80-11-01-400-801-F00).
J. Put the Airplane Back to Its Usual Condition
SUBTASK 80-11-01-410-005-F00
(1) Do this task: Close the Fan Cowl Panels, TASK 71-11-02-410-801-F00.
SUBTASK 80-11-01-860-021-F00
(2) For Engine 1, remove the safety tag and close this circuit breaker:
CAPT Electrical System Panel, P18-2
Row Col Number Name
B 8 C01103 ENGINE 1 START VALVE
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
80-11-01
Page 309
D633A101-ILF Feb 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
