TASK 24-34-21-400-801
3. Static Inverter - Installation
(Figure 401)
A. General
(1) The M9 Static Inverter is located on the E2-2 equipment rack in the main equipment center.
B. References
Reference Title
20-10-07-400-801 E/E Box Installation (P/B 201)
20-40-12-400-802 ESDS Handling for Metal Encased Unit Installation (P/B 201)
C. Expendables/Parts
AMM Item Description AIPC Reference AIPC Effectivity
1 Static inverter 24-34-21-01-005 ILF ALL
24-34-21-01-100 ILF 101, 151, 156-199,
301, 304, 308, 310, 314,
315, 317-319, 323,
331-399, 401, 402, 405,
424, 425, 427-429, 451,
452, 491-504, 507-510,
512-516, 518-520,
523-528, 530-533,
535-537, 541, 542,
552-557, 559-564,
567-569, 571-577, 581,
583, 585, 588-590,
592-599, 601-603, 606,
607, 610-615, 620,
625-627, 671, 672, 686,
691-699, 703, 707-710,
803-813, 821, 822,
831-838, 841, 842, 851,
852, 854-858, 861-863,
871-874, 947, 948,
968-973, 980-999
D. Location Zones
Zone Area
117 Electrical and Electronics Compartment - Left
E. Access Panels
Number Name/Location
117A Electronic Equipment Access Door
F. Static Inverter Installation
SUBTASK 24-34-21-480-001
WARNING
MAKE SURE THAT YOU REMOVE POWER FROM STATIC-INVERTER WIRE-
BUNDLE BEFORE YOU INSTALL STATIC INVERTER. WIRES WITH POWER
CAN CAUSE INJURY TO PERSONS.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-34-21
Page 406
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
