WARNING
KRYTOX 240AC IS AN AGENT THAT IS POISONOUS AND AN IRRITANT.
MAKE SURE ALL PERSONS OBEY THE PRECAUTIONS WHEN KRYTOX
240AC IS USED.
DO NOT USE IN AREAS WHERE THERE IS HIGH HEAT, SPARKS, OR
FLAMES.
CLOSE THE CONTAINER WHEN NOT USED.
DO NOT GET KRYTOX 240AC IN THE EYES, ON THE SKIN, OR ON
YOUR CLOTHES.
DO NOT BREATHE THE GAS.
DO NOT EAT KRYTOX 240AC.
(b) Apply a thin layer of Krytox 240AC perfluoropolyether grease, D50063 to the new
O-rings [16].
(c) Install an O-ring [16] on the flange of the high flow valve [14].
(d) Install an O-ring [16] on the flange of the air separation module [1].
(e) Put the sleeve [13] in its position between the high flow valve [14] and air separation
module [1].
(f) Make sure that the NEADS duct [27] and muscle air duct [9] align with the high flow
valve [14] and ASM mount.
(g) Install the coupling [15].
(h) Attach the muscle air duct [9] to the high flow valve [14].
(i) Attach the NEADS duct [27] to the high flow valve [14].
SUBTASK 47-11-01-420-005
(5) Tighten each setscrew [7] on the three ASM hose clamps [6] to 16 ±2 in-lb (1.8 ±0.2 N·m).
SUBTASK 47-11-01-410-002
(6) Put protective caps on the air separation module [1] for transport.
NOTE: This is to prevent contamination while the air separation module [1] is transported to
the airplane.
I. Air Separation Module Alternate Installation
SUBTASK 47-11-01-420-006
(1) Do these steps to install the air separation module [1] (Figure 402, View B):
(a) Apply a thin layer of compound, C00852, to the threads on the t-bolt of the strap [8].
(b) Apply the epoxy primer, C50285, to the groove where it comes in contact with the
straps [8].
(c) Put the aft insulation [62] on the air separation module [1].
(d) Remove the protective caps on each port.
(e) Align the three tie rods [50] to the ASM mounts [49] (Figure 402, View E).
(f) Install the bolt [53], washer [52], bushing [51], washer [54], and nut [55] through the ASM
mount [49] and tie rod [50] (three locations) (Figure 402, View A-A).
(g) Position the air separation module [1] into the strap [8] (Figure 402, View B).
1) Align all ports and ducts.
2) Hold the air separation module [1] in this position.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-11-01
Page 441
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590,
592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999;
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518,
524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703,
707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
