TASK 53-05-03-210-836
47. INTERNAL - GENERAL VISUAL: FORWARD PASSENGER COMPARTMENT, STA 360 to 663.75
(Figure 253)
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
231 Forward Passenger Compartment - Forward Entry Door to Sta 663.75 - Left
232 Forward Passenger Compartment - Forward Entry Door to Sta 663.75 - Right
B. Access Panels
Number Name/Location
833 Emergency Exit
843 Emergency Exit
S2301 Forward Passenger Compartment STA 360 to 663.75
C. Inspection
SUBTASK 53-05-03-010-033
(1) Open these access panels:
Number Name/Location
833 Emergency Exit
843 Emergency Exit
Special Access:
Number Name/Location
S2301 Forward Passenger Compartment STA 360 to 663.75
NOTE: Remove cabin interior as required. Remove/displace insulation blankets as required.
SUBTASK 53-05-03-210-036
(2) Do a General Visual inspection of the passenger compartment from STA 360 to 663.75,
including:
1. Skin panels (skins, frames and stringers), longitudinal lap splices, (note: inspection includes
the longitudinal lap splice at S-7L, and S-14L for the -800BCF), circumferential skin and
stringer splices (note: inspection includes the circumferential splice at STA 500H for the
-800BCF).
2. Window belt structure.
3. Overwing emergency exit cutout structure.
4. Forward cargo door cutout surround structure (portion in upper lobe).
5. STA 540 and 663 bulkheads and splices.
6. Overwing frames and stub beams.
7. Inspection area does not include the crown panel (skin, frames, shear ties, and stringers) at
STA 360 to STA 500H between S-4R and S-7L for the -800BCF.
SUBTASK 53-05-03-910-050
(3) 737-6789 Basic Task Description, AMM Task 51-05-01-210-808.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-03
Page 298.56
D633A101-ILF Jun 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
