2) If the contact bar is held with a rivet, make sure the contact bar can not be removed
from the connector.
NOTE: The contact bar is loose on the connector.
(f) If the terminal lug or stud is damaged, deformed, discolored or annealed, repair or
replaced the terminal lug (SWPM 20-62-25).
NOTE: If the terminal lug is annealed, use a high temperature terminal lug to replace the
lug (SWPM 20-30-11).
(g) Make sure the terminal nuts are tightened to a torque of 145 ±10 in-lb (16.4 ±1.1 N·m)
(SWPM 20-62-25).
NOTE: Do not pull or move the wires after the terminal nut is tightened.
(h) If the shipping plugs are installed, removed the shipping plugs.
NOTE: Wire type contacts have less contact surface.
(i) Put the connector together and install the two (2) bolts (SWPM 20-62-25).
1) Tighten the bolts to a torque of 32 ±2 in-lb (3.6 ±0.2 N·m).
(j) Make sure the wires are centered in the connector openings.
(k) Connect the battery sensor connector to the battery.
(l) Put the battery power connector into the battery receptacle on the battery.
1) Turn the knob on the connector clockwise with your hand until it is tight.
2) Use the double twist method to install the MS20995CY20 lockwire, G02479 from
the battery power connector knob to one of the connector bolts (Lockwire, Cotter
Pins, and Lockrings - Installation, TASK 20-10-44-400-801).
SUBTASK 24-31-11-860-059
(4) Remove the safety tags and close these circuit breakers:
Battery Shield, J9
Row Col Number Name
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 402, 405, 406, 409,
410, 412, 416, 424, 425, 427-429, 451, 452, 491-504, 507-510, 512-516, 518-520, 523-528, 530-533,
535-537, 541, 542, 552-557, 559-561, 563, 564, 567-569, 571-577, 581, 583, 585, 589, 590, 597-599,
601-603, 606, 607, 610-615, 620, 625-627, 671, 672, 691-699, 703, 803-813, 821, 822, 831, 832,
835-838, 841, 842, 851, 852, 857, 858, 947, 948, 968-973, 980-999
A 3 C01209 AUX BAT CHARGER
ILF ALL
A 4 C00142 BATTERY CHARGER
A 5 C01340 BATTERY BUS
ILF 493-500, 560-564, 567-569, 581, 583, 585, 588-590, 592-599, 601-603, 606, 607, 610-615, 620,
625-627, 671, 672, 691-699, 833-835, 838, 841, 842, 851, 852, 857, 858, 947, 948, 968-973, 980-999
SUBTASK 24-31-11-410-006
(5) Install the access cover on top of the J39 shield.
ILF ALL
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-31-11
Page 604
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
