SUBTASK 53-05-02-410-052
(3) Close this access door:
Number Name/Location
821 Forward Cargo Door
END OF TASK
TASK 53-05-02-250-840
60. INTERNAL - SPECIAL DETAILED: FORWARD CARGO DOOR SURROUND STRUCTURE
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
122 Forward Cargo Compartment - Right
124 Forward Cargo Compartment - Right
B. Access Panels
Number Name/Location
821 Forward Cargo Door
C. Inspection
SUBTASK 53-05-02-010-055
(1) Open this access panel:
Number Name/Location
821 Forward Cargo Door
NOTE: Removal of forward cargo door scuff plate is required to perform this inspection.
SUBTASK 53-05-02-250-040
(2) Do a Low Frequency Eddy Current inspection around the fasteners common to the web at the
lower main sill chords between STA 421 and 438 (for -600) and STA 461 and STA 478 (for
-700/-800).
See Doc. D626A001-DTR, DTR check form 53-30-08-12, for alternative inspections.
The NDI method(s) necessary to accomplish the intent of this inspection is contained in the
737 Nondestructive Test Manual (D6-37239). The inspection procedures are contained in Part
6, Subject 53-30-33.
SUBTASK 53-05-02-410-053
(3) Close this access panel:
Number Name/Location
821 Forward Cargo Door
END OF TASK
TASK 53-05-02-250-841
61. INTERNAL - SPECIAL DETAILED: FORWARD CARGO DOOR FITTINGS AND STOPS AT THE
FORWARD AND AFT EDGE FRAMES
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
122 Forward Cargo Compartment - Right
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-02
Page 233
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
