(Continued)
AMM Item Description AIPC Reference AIPC Effectivity
2 (cont.) 80-11-01-01A-060 ILF 317, 406, 424, 425,
427-429, 499, 500, 556,
560-564, 567-569, 581,
583, 585, 588-590,
592-599, 601-603, 606,
607, 610-615, 620,
625-627, 691-699,
833-835, 838, 948,
970-973, 980-999
F. Location Zones
Zone Area
411 Engine 1 - Engine
421 Engine 2 - Engine
G. Prepare for the Servicing
SUBTASK 80-11-01-010-017-F00
(1) Do this task: Open the Fan Cowl Panels, TASK 71-11-02-010-801-F00.
SUBTASK 80-11-01-860-019-F00
(2) For Engine 1, open this circuit breaker and install a safety tag:
CAPT Electrical System Panel, P18-2
Row Col Number Name
B 8 C01103 ENGINE 1 START VALVE
SUBTASK 80-11-01-860-020-F00
(3) For Engine 2, open this circuit breaker and install a safety tag:
F/O Electrical System Panel, P6-2
Row Col Number Name
C 4 C00154 ENGINE 2 START VALVE
H. Starter Servicing (Preferred Method)
SUBTASK 80-11-01-020-006-F00
(1) If not already done, do these steps to remove the magnetic plug [2]:
NOTE: Do not remove the magnetic plug housing or the safety cable. The removal of the
magnetic plug housing will drain the oil from the starter.
(a) Push the magnetic plug [2] with your hand and turn it counterclockwise until it stops.
NOTE: The magnetic plug is a bayonet type.
(b) Pull the magnetic plug [2] from the magnetic plug housing.
SUBTASK 80-11-01-680-004-F00
WARNING
DO NOT LET THE OIL STAY ON YOUR SKIN. USE THE OIL IN AN AREA WITH
GOOD VENTILATION. THE OIL IS POISONOUS AND CAN BE ABSORBED
THROUGH YOUR SKIN. THE OIL FUMES CAN IRRITATE YOUR
RESPIRATORY TRACT.
(2) Fill the starter with oil, D00599 [CP2442] as follows:
(a) Install the adapter, COM-2464 into the magnetic plug housing.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
80-11-01
Page 308
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
