Boeing 737-600 - Subtask 47-21-07-420-002; Subtask 47-21-07-430-004; Subtask 47-21-07-760-001; Subtask 47-21-07-865-001

47-AWL-01: CDCCL
(b) Make sure the electrical bonding resistance is 0.0005 ohm (0.5 milliohm) or less.
NOTE: CDCCL - Refer to the task: Airworthiness Limitation Precautions,
TASK 47-00-00-910-802, for important information on Critical Design
Configuration Control Limitations (CDCCLs).
NOTE: This is applicable to Airworthiness Limitation 47-AWL-01.
SUBTASK 47-21-07-420-002
47-AWL-01: CDCCL
(7) Apply a fillet seal between the flame arrestor [1] (bulkhead fitting) flange and the structure
outside the tank (aft side of the rear spar) (Figure 401).
NOTE: CDCCL - Refer to the task: Airworthiness Limitation Precautions,
TASK 47-00-00-910-802, for important information on Critical Design Configuration
Control Limitations (CDCCLs).
NOTE: This is applicable to Airworthiness Limitation 47-AWL-01.
(a) Use sealant, A00767, to apply the fillet seal.
SUBTASK 47-21-07-430-004
47-AWL-01: CDCCL
(8) Apply a fillet seal around the perimeter of the fitting (nut [3] (jam nut) and washer [2]) to the
tank wall inside the tank (forward side of the rear spar) (Figure 401).
NOTE: CDCCL - Refer to the task: Airworthiness Limitation Precautions,
TASK 47-00-00-910-802, for important information on Critical Design Configuration
Control Limitations (CDCCLs).
NOTE: This is applicable to Airworthiness Limitation 47-AWL-01.
(a) Use sealant, A00767, to apply the fillet seal.
SUBTASK 47-21-07-760-001
(9) Measure the electrical bonding resistance between the first tube that mates with the flame
arrestor [1] (bulkhead fitting) and the structure inside the tank (SWPM 20-20-00).
(a) Use an intrinsically safe approved bonding meter, COM-1550, to make the measurement.
(b) Make sure the electrical bonding resistance is 0.100 ohm (100 milliohms) or less.
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590, 592-599, 601-603, 606, 607,
610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999; ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315,
317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514,
516, 518, 524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703, 707-710, 803-813,
821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863, 871-874, 947, 948, 968-970, 972, 973 POST
SB 737-47-1003
J. Operational Test for the Flame Arrestor
SUBTASK 47-21-07-865-001
(1) Do these steps to prepare for the operational test:
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-21-07
Page 414
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 451, 452, 494-500, 503, 504, 509, 510, 514, 523-528, 541, 560-564, 567-569, 574-577, 581, 583, 585,
588-590, 592-599, 601-603, 606, 607, 610-615, 620, 625-627, 671, 672, 691-699, 832-835, 838, 856-858, 947,
948, 968-973, 980-999; ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 501, 502, 507, 508, 512, 513, 516, 518, 531-533, 535-537, 542,
552-556, 571-573, 686, 703, 707-710, 803-813, 821, 822, 831, 836, 837, 841, 842, 851, 852, 854, 855, 861-863,
871-874 POST SB 737-47-1002 OR POST SB 737-47-1003 OR POST SB 737-47-1015; ILF 491-493, 515,
519, 520, 530, 557, 559 POST SB 737-47-1002 OR POST SB 737-47-1015
