IDG SCAVENGE/CHARGE OIL FILTER - MAINTENANCE PRACTICES
1. General
A. This procedure contains scheduled maintenance task data.
B. This procedure has these tasks:
(1) IDG Scavenge and Charge Filter Removal
(2) IDG Scavenge and Charge Filter Inspection/Check
(3) IDG Scavenge and Charge Filter Installation.
TASK 24-11-41-000-801
2. IDG Scavenge and Charge Filter - Removal
(Figure 201)
NOTE: This procedure is a scheduled maintenance task.
A. General
(1) Identify the filter element that came out of the scavenge cavity and the charge cavity on the
IDG.
(2) If the IDG is to be replaced, put the element back into the cavity that it was removed from and
install the filter cover finger tight before you send the IDG to the repair shop.
(3) The IDG Scavenge Filter and Charge Filter elements are the same.
B. References
Reference Title
71-11-02-010-801-F00 Open the Fan Cowl Panels (P/B 201)
C. Expendables/Parts
AMM Item Description AIPC Reference AIPC Effectivity
2 Element 24-11-11-50-105 ILF ALL
3 O-ring 24-11-11-50-100 ILF ALL
D. Location Zones
Zone Area
410 Subzone - Engine 1
411 Engine 1 - Engine
420 Subzone - Engine 2
421 Engine 2 - Engine
E. Prepare for removal
SUBTASK 24-11-41-010-001
(1) Do this task: Open the Fan Cowl Panels, TASK 71-11-02-010-801-F00.
F. IDG Scavenge and Charge Filter Removal
SUBTASK 24-11-41-020-001
WARNING
DO NOT TOUCH THE COMPONENTS OF THE OIL SYSTEM IF THE ENGINE
IS HOT. THESE COMPONENTS STAY HOTTER THAN OTHER
COMPONENTS. HOT COMPONENTS CAN BURN YOU.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-11-41
Page 201
D633A101-ILF Feb 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
