ILF 625-627, 835, 838 (Continued)
(Continued)
F/O Electrical System Panel, P6-2
Row Col Number Name
B 7 C01319 ENGINE 2 START LEVER CHAN B
C 4 C00154 ENGINE 2 START VALVE
C 5 C01267 ENGINE 2 THRUST REVERSER SYNC LOCK
C 6 C01413 ENGINE 2 THRUST REVERSER INTLK
C 7 C00277 ENGINE 2 THRUST REVERSER CONT
C 8 C01004 ENGINE 2 THRUST REVERSER IND
D 4 C00459 ENGINE 2 IGNITION RIGHT
D 6 C00151 ENGINE 2 IGNITION LEFT
D 7 C01391 ENGINE 2 ALTN PWR CHAN B
D 8 C01315 ENGINE 2 ALTN PWR CHAN A
F/O Electrical System Panel, P6-3
Row Col Number Name
B 3 C00360 FUEL SPAR VALVE ENG 2
E 3 C01321 ENGINE FUEL ENGINE 2 HPSOV CONT
E 4 C01396 ENGINE FUEL ENGINE 2 HPSOV IND
SUBTASK 76-11-02-860-024-F00
(3) For the control stand lighting, open these circuit breakers and install safety tags:
Circuit Breaker Panel 5, P8
Row Col Number Name
--- --- C00320 ELEX PANEL LIGHTS FWD
F/O Electrical System Panel, P6-3
Row Col Number Name
C 10 C00284 PANEL & INSTR ELEX PANEL
SUBTASK 76-11-02-010-014-F00
(4) Do this task: Captain's and First Officer's Seat Removal, TASK 25-11-01-000-801.
SUBTASK 76-11-02-010-015-F00
(5) Put a mat on the aft electronics panel P8.
NOTE: This will prevent damage to the switches and glass surfaces of the indicators and
displays.
SUBTASK 76-11-02-010-013-F00
(6) Remove side cover [203] and side cover [222] from the control stand:
(a) Remove the eight quick-release fasteners [204] that hold the side cover [203] to the
control stand.
(b) Remove the 11 quick-release fasteners [204] that hold the side cover [222] to the control
stand.
(c) Remove the side cover [203], side cover [222].
