F. Remove the Pressure Switch
SUBTASK 47-43-01-010-002
(1) Go to the pressure switch [1] location.
NOTE: The pressure switch [1] is attached to the air filter inlet duct [6].
SUBTASK 47-43-01-020-003
(2) Disconnect the electrical connector [2].
SUBTASK 47-43-01-020-004
(3) Remove the applicable lockwire.
SUBTASK 47-43-01-030-002
(4) Disconnect the sense line [3].
NOTE: Use a second wrench to hold the pressure switch [1] when you disconnect the sense
line [3].
SUBTASK 47-43-01-030-003
(5) Loosen the nut [4].
NOTE: Use a second wrench to hold the boss [7] when you loosen the nut [4].
NOTE: The sense line [3] is rigid. Do not bend the sense line [3]when you remove the
pressure switch [1].
SUBTASK 47-43-01-020-001
(6) Remove the pressure switch [1].
NOTE: Keep the nut [4] for the installation.
(a) Discard the o-ring [5].
(b) Keep the washer [8]
SUBTASK 47-43-01-800-001
(7) Put protective caps on the sense line [3] and the duct [6] to keep out unwanted material.
END OF TASK
