(Continued)
Zone Area
114 Area Above and Outboard of Nose Landing Gear Wheel Well - Right
211 Flight Compartment - Left
212 Flight Compartment - Right
G. Access Panels
Number Name/Location
112A Forward Access Door
H. Thrust Lever Angle Resolver and Autothrottle Brake Assembly Installation
SUBTASK 76-11-05-420-007-F00
(1) Install the brake assembly [10] as follows:
(a) Apply grease, D00013 to the autothrottle shaft [49].
(b) Install the applicable brake assembly [10] on the autothrottle shaft [49].
SUBTASK 76-11-05-420-001-F00
(2) Install the spacer [42] as follows:
(a) Apply a layer of grease, D00013 to the inner side surface of the spacer.
(b) Install the spacer [42] on the autothrottle shaft [49].
SUBTASK 76-11-05-420-002-F00
(3) Prepare the TLA resolver [32] for installation as follows:
(a) If it is necessary, install these parts on the resolver:
1) Install the scraper [55].
2) Install seal nut [54].
a) Tighten the seal nut with the seal nut wrench to 0 in-lb (0 N·m) to 40 in-lb
(4.5 N·m) more than the run-on torque.
NOTE: The seal nut wrench is part of auto throttle servo assembly tool set,
SPL-2414.
b) Align the slot in the seal nut with the hole in the resolver for the cotter pin.
3) Install the cotter pin [56].
(b) Install the bearing [47].
(c) Put the plate [46] in its position.
(d) Install the three washers [48] and the three screws [43].
SUBTASK 76-11-05-420-003-F00
(4) Install the TLA resolver [32] as follows:
(a) Apply a layer of grease, D00013 to the inner side surface of the bearing [47].
(b) Install the TLA resolver [32] on the autothrottle shaft [49] and the spacer [42].
(c) Apply a layer of grease, D00013 to the inboard and inside surface of the spacer [45].
(d) Install the spacer [45] on to the autothrottle shaft.
(e) Put the nut [44] and the nut wrench onto the slotted shaft.
NOTE: The nut wrench is part of the auto throttle servo assembly tool set, SPL-2414.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-05
Page 414
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
