Boeing 737-600 - Pageblock 24-11-11;601 - INTEGRATED DRIVE GENERATOR (IDG) - INSPECTION;CHECK; Task 24-11-11-700-801 - Integrated Drive Generator - Disconnect and Reset Check; Subtask 24-11-11-010-002; Subtask 24-11-11-860-003

INTEGRATED DRIVE GENERATOR (IDG) - INSPECTION/CHECK
1. General
A. This task:
(1) The IDG Disconnect and Reset Check
TASK 24-11-11-700-801
2. Integrated Drive Generator - Disconnect and Reset Check
(Figure 601)
A. General
(1) The IDG is found on the accessory gearbox on the left side of the engine fan case.
(2) A disconnected IDG that remains mounted to an engine for about 50 flight hours can receive
damage to the ball bearing assembly for the IDG input shaft.
B. References
Reference Title
12-13-21-200-801 IDG Oil Level Check (P/B 301)
71-11-02-010-801-F00 Open the Fan Cowl Panels (P/B 201)
71-11-02-410-801-F00 Close the Fan Cowl Panels (P/B 201)
C. Location Zones
Zone Area
211 Flight Compartment - Left
212 Flight Compartment - Right
410 Subzone - Engine 1
411 Engine 1 - Engine
420 Subzone - Engine 2
421 Engine 2 - Engine
D. Prepare for the check
SUBTASK 24-11-11-010-002
(1) Do this task: Open the Fan Cowl Panels, TASK 71-11-02-010-801-F00.
SUBTASK 24-11-11-860-003
(2) Do this task: IDG Oil Level Check, TASK 12-13-21-200-801.
SUBTASK 24-11-11-860-004
(3) Make sure that these circuit breakers are closed:
F/O Electrical System Panel, P6-4
Row Col Number Name
F 8 C01286 GENERATOR DISC 1
F 9 C01287 GENERATOR DISC 2
F 10 C01283 GENERATOR CONT UNIT 1
F 11 C01284 GENERATOR CONT UNIT 2
E. Procedure
SUBTASK 24-11-11-710-001
(1) Do the check as follows:
(a) Push the BAT switch on the P5 panel to the ON position.
