Boeing 737-600 - Task 76-11-07-400-801-F00 - Autothrottle Switchpack Switch Installation

ILF ALL; AUTOTHROTTLE SWITCHPACK WITH REPLACEABLE SWITCHES P/N 254A1150-1, -2, -7, -8, -9, -10
(Continued)
(b) Remove the applicable switch [12].
(c) Remove the three switch wires from its associated connector as shown below
(Table 402):
Table 402/76-11-07-993-805-F00
Switchpack Switch Connector Pins
Left S1 D11128P 1, 2, 3
Left S2 D11130P 1, 2, 3
Left S3 D11130P 4, 5, 6
Left S4 D11128P 14, 7, 8
Left S5 D11130P 7, 8, 9
Left S6 D11130P 13, 14, 15
Left S7 D11128P 10, 11, 12
Left S8 D11128P 16, 17, 18
Left S9 D11128P 22, 23, 24
Right S1 D11132P 1, 2, 3
Right S2 D11134P 1, 2, 3
Right S3 D1134P 4, 5, 6
Right S4 D11132P 14, 7, 8
Right S5 D11134P 7, 8, 9
Right S6 D11134P 13, 14, 15
Right S7 D11132P 10, 11, 12
Right S8 D11132P 16, 17, 18
Right S9 D11132P 22, 23, 24
END OF TASK
TASK 76-11-07-400-801-F00
4. Autothrottle Switchpack Switch Installation
(Figure 401)
A. General
(1) This task provides the instructions on how to install an autothrottle switchpack switch on the
autothrottle switchpack assembly.
B. References
Reference Title
53-14-01-420-801 Nose Wheel Well Access Panels - Installation (P/B 401)
76-11-07-820-801-F00 Switch Check and Adjustment (P/B 501)
