TASK 53-05-03-210-817
20. INTERNAL - GENERAL VISUAL: AREA AFT OF FORWARD CARGO COMPARTMENT
(Figure 222)
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
125 Air Conditioning Distribution Bay - Left
126 Air Conditioning Distribution Bay - Right
B. Access Panels
Number Name/Location
S1203 Area Aft Of Forward Cargo Compartment Inspection
C. Inspection
SUBTASK 53-05-03-010-015
(1) Open this access panel:
Number Name/Location
S1203 Area Aft Of Forward Cargo Compartment Inspection
NOTE: Remove forward cargo compartment aft bulkhead panels. Remove/displace insulation
blankets as required. Remove ducting as required.
SUBTASK 53-05-03-210-017
(2) Do a General Visual inspection of the area aft of forward cargo compartment, including skin
panels (skins, frames, stringers), longitudinal lap splices, circumferential skin and stringer
splices, and forward side of Sta 540 bulkhead and bulkhead splices.
SUBTASK 53-05-03-910-020
(3) 737-6789 Basic Task Description, AMM Task 51-05-01-210-808.
SUBTASK 53-05-03-410-015
(4) Close this access panel:
Number Name/Location
S1203 Area Aft Of Forward Cargo Compartment Inspection
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-03
Page 267
D633A101-ILF Jun 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
