BATTERY - REMOVAL/INSTALLATION
1. General
A. This procedure contains scheduled maintenance task data.
B. This procedure has these tasks:
(1) A removal of the main battery and the auxiliary battery.
(2) An installation of main battery and the auxiliary battery.
TASK 24-31-11-000-802-002
2. Battery Removal
(Figure 401)
NOTE: This procedure is a scheduled maintenance task.
A. General
(1) The main battery, M6 is located below the E3 equipment rack in the main equipment area. The
auxiliary battery, M3054 is located just forward of the main battery.
(2) The main battery must be removed before you can remove the auxiliary battery. You do not
have to remove the auxiliary battery to replace the main battery. Both batteries are the same
part number.
(3) The batteries are removed and installed through a liner in the forward cargo area. The circuit
breakers for both batteries are installed on the J9 panel in the main equipment center.
B. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-1633 Equipment - Battery Installation
737-600, -700, -800
Part #: C24003-1 Supplier: 81205
C. Location Zones
Zone Area
117 Electrical and Electronics Compartment - Left
118 Electrical and Electronics Compartment - Right
121 Forward Cargo Compartment - Left
122 Forward Cargo Compartment - Right
D. Access Panels
Number Name/Location
117A Electronic Equipment Access Door
E. Prepare for the removal
SUBTASK 24-31-11-860-009-002
(1) Make sure the BAT switch on the P5-13 panel is set to the OFF position.
SUBTASK 24-31-11-860-010-002
(2) Make sure the STANDBY POWER switch on the P5-5 panel is set to the AUTO position.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-31-11
Config 2
Page 401
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401,
402, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 452, 491-504, 507-510,
512-516, 518-520, 523-528, 530-533, 535-537, 541, 542, 552-557, 559-561, 563,
564, 567-569, 571-577, 581, 583, 585, 589, 590, 597-599, 601-603, 606, 607,
610-615, 620, 625-627, 671, 672, 691-699, 703, 803-813, 821, 822, 831, 832,
835-838, 841, 842, 851, 852, 857, 858, 947, 948, 968-973, 980-999
To Next Page
