SUBTASK 47-31-01-010-003
(2) Open this access panel:
Number Name/Location
821 Forward Cargo Door
SUBTASK 47-31-01-860-001
(3) Make sure that the L PACK and R PACK switches, on the P5-10 air conditioning panel, are in
the OFF position.
SUBTASK 47-31-01-010-004
(4) Remove the aft center bulkhead liner in the forward cargo compartment
(TASK 25-52-17-000-801).
F. Remove the Controller
SUBTASK 47-31-01-020-001
(1) Do these steps to remove the controller [1]:
(a) Disconnect the two electrical connectors [3] from the controller [1].
1) Move the electrical connectors [3] out of the way.
NOTE: The two electrical connectors [3] have ground wires attached to them.
These are for electrical bonding. Use caution to not damage the ground
wires or their connections to the airplane structure.
(b) Remove the four screws [10] and washers [11] to remove the drip shield [2].
(c) Remove the drip shield [2].
(d) Remove the four screws [6] and washers [7] from the controller [1] vibration isolator [8].
(e) Pull the controller [1] away from the brackets [5] to remove it.
NOTE: The bonding jumpers [9] will stay with the controller [1]. Make sure you do not
damage them when you remove the controller [1].
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-31-01
Page 402
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590,
592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999;
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518,
524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703,
707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
